US API High-pressure ball valve Q41N/Q61N/Q11N Primarily used in long-distance pipeline transportation of oil and natural gas, and in urban gas pipeline systems. Due to the unique characteristics of valves for long-distance pipelines, their design fully considers their ability to withstand pipeline stress, as well as safety, weather resistance, and long-term reliability; the sealing and structural design are unique to Jian Valve Company. Suitable for Class 150～2500Lb, operating temperatures 80～550℃ in long-distance pipelines and general industrial pipelines, their safety and resistance to harsh environments have been specially considered, suitable for media such as water, روغن, and steam.
نام محصول: High-Pressure Ball Valve
مدل محصول: Q41N/Q61N/Q11N
قطر اسمی: DN15-DN300
نوع ساختار: کروی
فشار اسمی: 1.6Mpa~32.0Mpa, Class 150～2500Lb
روش اتصال: فلنج, Welding, Internal Thread, External Thread
دمای قابل اجرا: ≤550ºC
روش فعال سازی: برقی, پنوماتیک
جنس بدنه سوپاپ: فولاد آهنگری, فولاد ضد زنگ
استاندارد ساخت: گیگابایت (استاندارد ملی چین), از (استاندارد آلمان), API (استاندارد آمریکا), ANSI (استاندارد آمریکا)
رسانه های کاربردی: آب, روغن, Steam, گاز, Natural Gas
سازنده:شرکت شیر ژجیانگ کوزو, Ltd.
US API High-pressure ball valve Q41N/Q61N/Q11N product description
High-pressure ball valves are mainly used for long-distance pipeline transportation of oil and natural gas and city gas pipeline systems. Due to the unique characteristics of the valve for long-distance pipelines, its ability to withstand pipeline stress, as well as safety, weather resistance, long-term reliability, و غیره. are fully considered during design. The sealing and structural design are unique to Kelico Company. It is suitable for long-distance pipelines and general industrial pipelines with Class 150~2500Lb and operating temperature of 80~550℃. Special considerations have been taken in its design of safety and harsh environment resistance. It is suitable for water, روغن, بخار, گاز, natural gas and other media.
US API High-pressure ball valve Q41N/Q61N/Q11N Product features
1. All parts of this product are forgings
2. Adopt bottom-mounted valve stem and equipment inverted sealing structure
3. Adopt an inlaid valve seat, and an O-ring is installed behind the valve seat to ensure that the medium does not leak.
4. The sealing surface is made of nylon 1010. Its friction coefficient is usually 1/3 of that of Babbitt alloy, so it is a naturally slippery material. However, its bending strength, impact strength and high ductility are comparable to those of metal.
5. The sealing surface is made of STL alloy, which is wear-resistant and high-temperature resistant.
6 Anti-static and fire-proof design.
Design Standards (استاندارد آمریکا)
Design and manufacturing standards are in accordance with: ASME B16.34, API6D, و غیره;
Structural length is in accordance with: ASME B16.10;
The connection end dimensions are in accordance with: ASME B16.5, ASME B16.25;
Inspection and testing in accordance with: API598;
Fire protection design is in accordance with: API607;
Tendering standards (national standards)
Design and manufacturing standards are in accordance with: GB12237-1989 General valves Flange and butt welded steel ball valves
The structural length is in accordance with: GB12221;
The connection size is in accordance with: JB/T79, GB9113, HG20592;
Inspection and testing in accordance with: JB/T 9092, GB/T13927-1992 General valve pressure test
US API High-pressure ball valve Q41N/Q61N/Q11N Main parts materials
Part name Material
GB ASTM
Spring 60SizMnl AISI9260
صندلی سوپاپ 25 A105
Seal PTFE PTFE
O-ring NBR NBR
Screw 35CrMo A193-B7
Gasket PTFE flexible graphite
Lower stem 2Cr13 A276-410
Gasket PTFE flexible graphite
Bottom cover 25 A105
بدنه سوپاپ, end 25 A105
Gasket PTFE flexible graphite
O-ring NBR NBR
Sphere A105+HCr
Sliding bearing PTFE
Valve stem 2Cr13 A276-410
Grease valve components
Gasket PTFE+stainless steel PTFE+304
Stuffing box 25 A105
Gland 25 A105
O-ring NBR NBR
Bracket Q235A carbon steel
کلید 45 AISI C 1045
Connecting sleeve 45 AISI C 1045
Drive components (electric or pneumatic)
Key performance specifications
Model Q41N/Y-160 Q41N/Y-320 Q61N/Y-160 Q61N/Y-320
Nominal pressure PN (MPa) 16.0 32.0 16.0 32.0
Test pressure
(Mpa) Shell 24.0 48.0 24.0 48.0
Seal (مایع) 17.6 35.2 17.6 35.2
Sealing (air) 0.6
Applicable temperature -40～80
Applicable media: water, روغن, helium, hydrogen, ammonia, و غیره.
