Q11N-160P, 320P Hogedrukkogelkraan met binnendraad
The Q11N-160P/320P internal thread high-pressure ball valve is mainly used in long-distance oil and natural gas pipeline systems. Due to the unique characteristics of valves used in long-distance pipelines, its design fully considers its ability to withstand pipeline stress, as well as safety, weather resistance, and long-term reliability; the sealing and structural design are unique to Jian Valve Company. It is suitable for Class 150～2500Lb long-distance pipelines and general industrial pipelines with operating temperatures of 80～550℃. Its safety and resistance to harsh environments have been specially considered in its design, making it suitable for media such as water, olie, stoom, gas, and natural gas.
Productnaam: Internal Thread High-Pressure Ball Valve
Productmodel: Q11N-160P/320P
Nominale diameter: DN15～DN50
Structure Type: Ball
Nominale druk: 1.6Mpa~32.0Mpa, Class 150～2500Lb
Verbindingsmethode: Internal Thread
Toepasselijke temperatuur: ≤550ºC
Activeringsmethode: Electric, Pneumatisch
Materiaal kleplichaam: Forged Steel, Roestvrij staal
Productiestandaard: GB (Chinese nationale standaard), VAN (Duitse standaard), API (Amerikaanse standaard), ANSI (Amerikaanse standaard)
Toepasselijke media: Water, Olie, Steam, Gas, Natural Gas
Fabrikant:Zhejiang Kozo Valve Co., Ltd.
Q11N-160P, 320P Internal Thread High-Pressure Ball Valve product description
Q11N-160P/320P internal thread high-pressure ball valve is mainly used in long-distance pipeline transportation systems for oil and natural gas. Due to the unique characteristics of the valve for long-distance pipelines, its ability to withstand pipeline stress, as well as safety, weather resistance, long-term reliability, enz. are fully considered during design. The sealing and structural design are unique to Kelico Company. It is suitable for long-distance pipelines and general industrial pipelines with Class 150~2500Lb and operating temperature of 80~550℃. Special considerations have been taken in its design of safety and harsh environment resistance. It is suitable for water, olie, stoom, gas, natural gas and other media.
Q11N-160P, 320P Internal Thread High-Pressure Ball Valve Product features
1. All parts of this product are forgings
2. Adopt bottom-mounted valve stem and equipment inverted sealing structure
3. Adopt an inlaid valve seat, and an O-ring is installed behind the valve seat to ensure that the medium does not leak.
4. The sealing surface is made of nylon 1010. Its friction coefficient is usually 1/3 of that of Babbitt alloy, so it is a naturally slippery material. However, its bending strength, impact strength and high ductility are comparable to those of metal.
5. The sealing surface is made of STL alloy, which is wear-resistant and high-temperature resistant.
6 Anti-static and fire-proof design.
Q11N-160P, 320P Internal Thread High-Pressure Ball Valve Design Standards (Amerikaanse standaard)
Design and manufacturing standards are in accordance with: ASME B16.34, API6D, enz.;
Structural length is in accordance with: ASME B16.10;
The connection end dimensions are in accordance with: ASME B16.5, ASME B16.25;
Inspection and testing in accordance with: API598;
Fire protection design is in accordance with: API607;
Tendering standards (national standards)
Design and manufacturing standards are in accordance with: GB12237-1989 General valves Flange and butt welded steel ball valves
The structural length is in accordance with: GB12221;
The connection size is in accordance with: JB/T79, GB9113, HG20592;
Inspection and testing in accordance with: JB/T 9092, GB/T13927-1992 General valve pressure test
Main parts materials
Part name Material
GB ASTM
Spring 60SizMnl AISI9260
Valve seat 25 A105
Seal PTFE PTFE
O-ring NBR NBR
Screw 35CrMo A193-B7
Gasket PTFE flexible graphite
Lower stem 2Cr13 A276-410
Gasket PTFE flexible graphite
Bottom cover 25 A105
Valve body, end 25 A105
Gasket PTFE flexible graphite
O-ring NBR NBR
Sphere A105+HCr
Sliding bearing PTFE
Valve stem 2Cr13 A276-410
Grease valve components
Gasket PTFE+stainless steel PTFE+304
Stuffing box 25 A105
Gland 25 A105
O-ring NBR NBR
Bracket Q235A carbon steel
Key 45 AISI C 1045
Connecting sleeve 45 AISI C 1045
Drive components (electric or pneumatic)
