AF-460 不锈钢法兰浮球阀
The stainless steel flanged float valve is composed of a stainless steel valve body and a stainless steel float. The interface is designed in the form of a flange, which is more conducive to installation and easy disassembly. The stainless steel flanged float valve is designed based on hydraulic principles and has the advantages of compact structure, reliable opening and closing action, high sensitivity, low head loss, and no water hammer phenomenon. It is also lightweight, small in size, and easy to install and maintain. It is widely used in automatic water supply systems of various water tanks, pools, and towers in industrial and mining enterprises and civil buildings. It can also be used as a control valve for circulating water supply in atmospheric pressure boilers.
Low Temperature Resistant Soft Seal Float ValveThe AF-89 float valve belongs to the ball valve category. It is a piston valve with a float aded. It uses the lever principle and the rising or falling of the float to control the opening and closing of the piston valve. When the float rises, the piston valve slowly closes; when the float sinks, the piston valve slowly opens, making it a device for controlling water level.
The float valve is made entirely of stainless steel through die-casting technology, which ensures a perfect fit between the components and prevents corrosion, loosening, or jamming. This ensures that the ball valve can work stably for a long time. At the same time, the stainless steel components prevent chemical corrosion in high-humidity environments, keeping the drinking water pure and healthy.
The float valve features a unique dual-rod buoyancy transmission, which significantly increases the buoyancy of the ball, achieving a sealing pressure of over 8 kg, far exceeding the national standard of 6 kg. Combined with a vertical valve core for stable transmission, this comprehensively solves the problem of float valves easily failing due to unbalanced force on the valve core, ensuring the reliable operation of the float valve.
Product Name: Float Valve
Product Model: AF-460
Nominal Diameter: DN15～DN300
Structure Type: Lever Type
Nominal Pressure: 0.03Mpa～1.6Mpa
Connection Method: Flange, Threaded
Applicable Temperature: ≤100ºC
Actuation Method: Level Control
Valve Body Material: Stainless Steel, Copper
Manufacturing Standard: 国标 (Chinese National Standard), 从 (German Standard), 应用程序编程接口 (American Standard)
Applicable Media: Water, Oil, Liquids
Manufacturer: 浙江科三阀门有限公司, 有限公司.
AF-460 Stainless steel flange float valve Application characteristics
KOZO VALVE’s float valves utilize hydraulic design principles, featuring a lightweight structure, reliable opening and closing actions, high sensitivity, low head loss, and no water hammer. They are also characterized by their light weight, small size, and convenient installation and maintenance. KOZO VALVE’s quality – honed over ten years – is unmatched in the market. Widely applicable to automatic water supply systems in industrial and mining enterprises, and civil buildings for various water tanks, pools, and towers, they can also be used as control valves for circulating water supply in atmospheric pressure boilers.
AF-460 Stainless steel flange float valve Working principle
Working principle of float valve: When the water level in the pool (tower) drops, the float falls, and the pressure of the water in the pipeline opens the sealing surface of the ball valve, and the valve body opens to supply water. When the water level in the pool (tower) rises, the float rises, drives the small plunger, closes the small hole, and the sealing surface is sealed, and the valve stops supplying water.
Float Valve Performance Characteristics
Operating Medium: Water, Oil, Liquid
Medium Temperature: ≤100ºC
Operating Pressure: 0.03Mpa-0.6Mpa
Custom Pressure: 1.0Mpa-1.6Mpa
Manufacturing Materials: Stainless Steel, Copper
Sealing Materials: Nitrile Rubber, Silicone
(High-temperature resistant float valves in various specifications from DN40 to DN300 with operating medium temperatures ≤150ºC are available upon request, according to user needs.)
The float valve is designed to allow consumers to easily control the water level in a pool without changing the piping configuration. This product features a specially improved float linkage design with the addition of a level adjustment gear assembly, allowing the water level to be adjusted arbitrarily within the length of the adjusting rod to meet the needs of different situations.
